Picture of 1mak

1mak

Project Developer

7017

372

2025

General Info

My favorite things in life don't cost any money. It's really clear that the most precious resource we all have is time.
  • I am from
    Brisbane Queensland
  • My work
    Web Developer simPRO
  • My Interests
    Photography, Videography, Web Design, Offroading, Camping, Cooking

Member Activities

Picture of 1mak
1mak Someone liked your Topic
16. Sep 2021 - 08:48
Picture of 1mak
1mak created a new forum topic
14. Sep 2021 - 07:36
Picture of 1mak
1mak posted in a forum topic
9. Sep 2021 - 22:12

The next bit was to connect the positive and the earth. The earth is the easiest. There are a couple of unpainted screws/bolts under the tub where this can be easily attached to. It takes a bit more fiddling around with the positive cable which needs to go all the way to the front, right next to the fuse box.

While running it under the frame I tried to avoid it being too close to any exhaust pipes or moving parts and at some point, you have to cross sides because while the outlet will be on the right sight of the bed, the battery terminal and the fuse box will be on the left. I found a nice clean cross member under the frame where I was able to find a clean and clear path for the cable.

If you got the accessory option like me, you can count yourself lucky. This will make your life a whole lot easier. All I had to do is, find the accessory pigtail which sits between the frame and the fuse box. It's essentially a bunch of 4 different wires of different diameters wrapped in electrical tape. Unwrap it and the wires will come free. Now you can connect your positive directly to one of the wires. I chose the second-thickest of them which is protected by a 30-amp fuse and stuck an additional 30-amp inline fuse in between (probably wasn't necessary).

This now will let you use one of the buttons in the accessory switch panel in your dashboard. You can set the function of each of these 4 buttons in your uConnect system. Go to Accessories and now you can select whether a button acts as a temporary or permanent switch, whether they work with the ignition off or in ACC mode, and whether the car memorizes whether you had the button enabled or disabled the last time you drove your Gladiator.

All in all the installation took about just over an hour and was pretty easy. 100% recommend. The only thing I'd change next time is to choose a double outlet or an extra USB outlet. :)

Side note:

I've run my 55L Waeco fridge for a full two weeks on our last trip through this outlet. I believe because the car has the Electronic Start Stop system which uses an additional smaller battery while the accessories run through the big battery you will never have to worry about the car not starting because of a drained battery. Maybe someone can confirm my theory?


Read more
Picture of 1mak
1mak posted in a forum topic
9. Sep 2021 - 22:10

The next bit was to connect the positive and the earth. The earth is the easiest. There are a couple of unpainted screws/bolts under the tub where this can be easily attached to. It takes a bit more fiddling around with the positive cable which needs to go all the way to the front, right next to the fuse box.While running it under the frame I tried to avoid it being too close to any exhaust pipes or moving parts and at some point, you have to cross sides because while the outlet will be on the right sight of the bed, the battery terminal and the fuse box will be on the left. I found a nice clean cross member under the frame where I was able to find a clean and clear path for the cable.If you got the accessory option like me, you can count yourself lucky. This will make your life a whole lot easier. All I had to do is, find the accessory pigtail which sits between the frame and the fuse box. It's essentially a bunch of 4 different wires of different diameters wrapped in electrical tape. Unwrap it and the wires will come free. Now you can connect your positive directly to one of the wires. I chose the second-thickest of them which is protected by a 30-amp fuse and stuck an additional 30-amp inline fuse in between (probably wasn't necessary). This now will let you use one of the buttons in the accessory switch panel in your dashboard. You can set the function of each of these 4 buttons in your uConnect system. Go to Accessories and now you can select whether a button acts as a temporary or permanent switch, whether they work with the ignition off or in ACC mode, and whether the car memorizes whether you had the button enabled or disabled the last time you drove your Gladiator.All in all the installation took about just over an hour and was pretty easy. 100% recommend. The only thing I'd change next time is to choose a double outlet or an extra USB outlet. :)Side note:I've run my 55L Waeco fridge for a full two weeks on our last trip through this outlet. I believe because the car has the Electronic Start Stop system which uses an additional smaller battery while the accessories run through the big battery you will never have to worry about the car not starting because of a drained battery. Maybe someone can confirm my theory?


<
Read more
Picture of 1mak
1mak posted in a forum topic
9. Sep 2021 - 22:07

The next bit was to connect the positive and the earth. The earth is the easiest. There are a couple of unpainted screws/bolts under the tub where this can be easily attached to. It takes a bit more fiddling around with the positive cable which needs to go all the way to the front, right next to the fuse box.While running it under the frame I tried to avoid it being too close to any exhaust pipes or moving parts and at some point, you have to cross sides because while the outlet will be on the right sight of the bed, the battery terminal and the fuse box will be on the left. I found a nice clean cross member under the frame where I was able to find a clean and clear path for the cable.If you got the accessory option like me, you can count yourself lucky. This will make your life a whole lot easier. All I had to do is, find the accessory pigtail which sits between the frame and the fuse box. It's essentially a bunch of 4 different wires of different diameters wrapped in electrical tape. Unwrap it and the wires will come free. Now you can connect your positive directly to one of the wires. I chose the second-thickest of them which is protected by a 30-amp fuse and stuck an additional 30-amp inline fuse in between (probably wasn't necessary). This now will let you use one of the buttons in the accessory switch panel in your dashboard. You can set the function of each of these 4 buttons in your uConnect system. Go to Accessories and now you can select whether a button acts as a temporary or permanent switch, whether they work with the ignition off or in ACC mode, and whether the car memorizes whether you had the button enabled or disabled the last time you drove your Gladiator.All in all the installation took about just over an hour and was pretty easy. 100% recommend. The only thing I'd change next time is to choose a double outlet or an extra USB outlet. :)Side note:I've run my 55L Waeco fridge for a full two weeks on our last trip through this outlet. I believe because the car has the Electronic Start Stop system which uses an additional smaller battery while the accessories run through the big battery you will never have to worry about the car not starting because of a drained battery. Maybe someone can confirm my theory?


Read more
Picture of 1mak
1mak posted in a forum topic
9. Sep 2021 - 21:54

The first thing to do was to take a carpet knife and cut through the spray bedliner on the rear side of the bed to get access to a rectangular grommet. This will be the base for the 12-Volt plug, it can be screwed right in (and I used a bunch of hot glue to secure it a bit more). There is a lot of space from underneath the truck bed, so you can easily get your hand in and push the grommet out from the other side.


Read more
Picture of 1mak
1mak created a new forum topic
9. Sep 2021 - 21:50
Picture of 1mak
1mak posted in a forum topic
9. Sep 2021 - 21:38

Here are a couple of pictures of the 35" tires on my Gladiator which should give you a good idea of whether you'd like to go down the same track or not. :)


Read more
Picture of 1mak
1mak created a new forum topic
9. Sep 2021 - 21:36
Picture of 1mak
1mak , someone liked your picture
14. Jul 2021 - 10:22
Picture of 1mak
1mak , someone liked your picture
24. May 2021 - 16:18
Picture of 1mak
1mak , someone liked your picture
22. May 2021 - 23:31
Picture of 1mak
1mak , someone liked your picture
22. May 2021 - 23:31
Picture of 1mak
1mak , someone liked your picture
7. May 2021 - 09:18
Picture of 1mak
1mak , someone liked your picture
20. Mar 2021 - 21:21
Picture of 1mak
1mak , someone liked your picture
27. Jan 2021 - 19:30
Picture of 1mak
1mak liked 1mak's post
26. Jan 2021 - 10:42

You're lucky! Someone just posted a link to it on Facebook :) https://www.google.com/maps/d/...


Read more
Picture of 1mak
1mak , someone liked your picture
11. Jan 2021 - 15:53
Picture of 1mak
1mak , someone liked your picture
11. Dec 2020 - 16:02
Picture of 1mak
1mak , someone liked your picture
7. Dec 2020 - 22:42
Picture of 1mak
1mak , someone liked your picture
1. Nov 2020 - 19:14
Picture of 1mak
1mak posted in a forum topic
16. Oct 2020 - 16:49
Picture of 1mak
1mak liked 1mak's post
5. Oct 2020 - 10:12

You're lucky! Someone just posted a link to it on Facebook :) https://www.google.com/maps/d/...


Read more
Picture of 1mak
1mak , someone liked your picture
30. Sep 2020 - 03:49
Picture of 1mak
1mak , someone liked your picture
17. Sep 2020 - 18:38
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:56
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:56
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:56
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:56
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:56
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:56
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:56
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:56
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:56
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:56
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:56
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:56
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:56
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:56
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:56
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:56
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:56
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:56
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:56
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:56
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:56
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:56
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:56
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:56
Picture of 1mak
1mak New Picture
16. Sep 2020 - 08:55
